Description
Specification:
HDMI version: HDMI 4k 30hz
HDCP version: HDCP1.2
HDMI resolution : 24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i
Support video color format: 24bit/deep color 30bit,36bit
Support audio format: DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD
Max bandwidth: 225MHz
Max transmission bandwidth: 6.75Gbps
Input/Output TMDS signal: 0.5~1.5Volts p-p(TTL)
Input/Output DDC signal :5Volts p-p (TTL)
Input cable distance: ≤ 15m AWG26 HDMI 1.3 standard cable
Output cable distance: ≤ 25m AWG26 HDMI 1.3 standard cable
Max working current: 2.4A
Power adapter format..Input: AC (50HZ, 60HZ) 100V-240V; Output: DC5V/1A,DC5v/1A
Operating Temperature range: (-15 to +55°C)
Operating Humidity range : 5 to 90%RH (No Condensation)
