Description
- General Parameters
- Product dimensions (width x height x depth)241.3 mm × 140.8 mm × 156.3mm
- Packaging dimensions (width × height × depth)320mm ×265mm ×55mm
- net weight0.245 kg
- Packing List
1500Mbps Wi-Fi6 Router x 1
Power Supply Adaptor × 1
CAT5e Network Cable × 1
Quick Start Guide × 1
Regulatory Compliance and Safety Information × 1
- Packing formSingle pack
- Operating temperature0℃ to 40℃ (32℉ to 104℉)
- Operating humidity10% to 90% RH non-condensing
- Storage temperature-40℃ to 70℃ (-40℉ to 158℉)
- Storage humidity5% to 95% RH non-condensing
- InstallationDesk-Mounted,Wall-Mounted
- Gross weight0.790 kg
- Wireless parameters
- Wireless Standards
IEEE 802.11a/n/ac/ax @5GHz
IEEE 802.11b/g/n @2.4GHz
- Operating frequency band2.4 GHz，5 GHz
- Transmit power
THIS:
＜20dBm(2.4GHz)
＜23dBm(5GHz)
- Receive sensitivity
5GHz:
-89dBm@HE80-MCS0
-60dBm@HE80-MCS11
2.4GHz:
-93dBm@HT40-MCS0
-73dBm@HT40-MCS7
- antenna4 high gain antennas
- Wireless rangeUp to 1300 ft²/120 m²
- Maximum number of connections128
- Recommended access number50
- Wireless Features
Dual Band Supported
MU-MIMO supported
Beamforming supported
OFDMA supported
- Antenna gain5dbi
- Maximum transmission rate
≤ 1500 Mbps
5GHz: 1201Mbps
2.4GHz: 300Mbps
- Hardware Features
- Network port
1 × 10/100/1000 Mbps Adaptive WAN Port
3 × 10/100/1000 Mbps Adaptive LAN Ports
- LED indicatorsRed/blue for different working states, flashing mode
- Power supply modePower Supply Adapter
- Power specificationsDC 12V, 1A
- buttonReset button, WPS Button
- Running memory128MB DDR2
- Built-in memory128MB NAND
- Maximum power consumption of the whole machine≤10 W
- Software Features
- Safe ModeWPA2-PSK,WPA/WPA2-PSK supported
- DHCP
DHCP Client List
DHCP Server
- Security Mechanism
Support fast and secure WPS connection
Support hiding wireless network name
Support controlling terminal network connection
Support firewalls
Login Authentication
- Management methods
Web Control: PC, mobile
App Control: HPP, HC
TR069(TR098/TR181)
- Software upgrade
Web Upgrade
App Cloud Upgrade
Auto Upgrade
- System logSystem log
- Working Mode
Router Mode
Wireless Extender Mode
Access Point Mode
- WAN Mode
DHCP
Static IP
PPPOE
- IP version
IPv4
IPv6
- Parent Management
Speed Limit
Internet Access Period
Filter URL
Parental Control
Custom Profiles
- Firewall
Forbid UDP flood attack
Forbid TCP SYNC flood attack
Forbid ICMP flood attack
- DDNSsnake
- VPN
PPTP Client
L2TP Client
- NAT forwarding
Port Mapping
DMZ
UPnP
- Other FeaturesVLAN/IPTV,WAN Self-Adaption,Quick Diagnosis,WIFI Optimization
- MESHHikvision Mesh
