Description
- Camera
- Image Sensor2 MP CMOS
- Signal SystemPAL/NTSC
- Max. Resolution1920 (H) × 1080 (V)
- Min. Illumination0.02 Lux @ (F1.2, AGC ON), 0 Lux with IR
- Shutter TimePAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
- Day & NightIR Cut Filter
- Angle AdjustmentPan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360°
- Lens
- Lens Type2.8 mm, 3.6 mm Fixed Lens
- Focal Length & FOV
2.8 mm, horizontal FOV: 96.5°, vertical FOV: 48.9°, diagonal FOV: 120.5°
3.6 mm, horizontal FOV: 76.9°, vertical FOV: 40.6°, diagonal FOV: 92.0°
- Lens MountM12
- Illuminator
- Supplement Light RangeUp to 20 m
- Supplement Light TypeSmart,IR,White Light
- Image
- Frame Rate
TVI: 1080p@25fps/30fps
AHD: 1080p@25fps/30fps
CVI: 1080p@25fps/30fps
CVBS: PAL/NTSC
- Wide Dynamic Range (WDR)Digital WDR
- Image Parameters SwitchSTD/HIGH-SAT
- Day/Night ModeAuto/Color
- White BalanceAuto
- Image EnhancementDWDR, BLC, Global
- Noise Reduction2D DNR
- Image SettingsBrightness, Mirror, Smart IR, Sharpness, AGC
- Interface
- Video OutputSwitchable TVI/AHD/CVI/CVBS
- General
- LanguageEnglish
- Operating Condition-40°C to 60°C (-40°F to 140°F), Humidity: 90% or less (non-condensing)
- MaterialPlastic
