Description
| Specifications | |
|---|---|
| Model | CS-C60p-R100-8H33WF |
| Camera | |
| Image Sensor | 1/2.7″ Progressive Scan CMOS |
| Shutter Speed | Self-adaptive shutter |
| UP Lens |
2.8mm@F1.6 , view angle: 108° (Horizontal), 103°(Vertical) |
| DN Lens |
2.8mm@F1.6 , view angle: 108° (Horizontal), 103°(Vertical) |
| Lens Mount | M12 |
| Day & Night | IR-cut filter with auto-switching |
| DNR | 3D DNR |
| WDR | Digital WDR |
| Compression | |
| Video Compression | H.264/H.265 |
| Video Bit Rate | Adaptive bit rate |
| Image | |
| Max. Resolution |
Upper camera: 2K (2048 × 1296) Bottom camera: 2K (2048 × 1296) |
| Frame Rate | Max. 15fps; Self-adaptive during network transmission |
| Network | |
| Smart Alarm | Motion detection, AI-powered human shape detection, patrol mode detection |
| Pairing | Bluetooth pairing |
| Protocol | EZVIZ cloud proprietary protocol |
| Interface Protocol | EZVIZ cloud proprietary protocol |
| Interface | |
| Storage | Supports microSD card (max. 512 GB) |
| Power | Type-C |
| Wi-Fi | |
| Standard | IEEE802.11b, 802.11g, 802.11n, 802.11ac, 802.11ax |
| Frequency Range |
2.4GHz: 2.4 GHz ~ 2.4835 GHz 5GHz: 5.150GHz~5.250GHz |
| Channel Bandwidth |
2.4GHz Supports 20MHz 5GHz Supports 80MHz |
| Security | WPA-PSK, WPA2-PSK,WPA3-Personal |
| Transmission Rate |
2.4GHz Max. Rate Support: 11b_11M, 11g_54M, 11n_MCS7_20M, 11ax_MCS11_20M 5.15-5.25GHz Max. Rate Support: 11a_54M, 11n_MCS7_20-40M, 11ac_MCS9_20-40-80M, 11ax_MCS11_20-40-80M |
| Output Power(EIRP) | 20 dBm |
| Antenna Gain | 2.56dBi@2.48GHz, 3.18dBi@5.22GHz |
| General | |
| Operating Conditions | -10°C to 45°C, Humidity 95% or less (non-condensing) |
| Power Supply | DC 5V/2A |
| Power Consumption | 8W max |
| IR Range | MAX. 10 meters (33ft) |
